For trouble free working these connecting cables are just as important as winding wires for the submersible pump & motors. MEHAL CABLE 3 core flat cables are Manufactured keeping in mind the severely difficult conditions in which they are required to operate. The wires are drawn, annealed and bunched properly to ensure long life. Each of these three flexible copper conductors are insulated with a specially formulated PVC compound and the cores are laid-up in flat paralled position. The outer sheath of the cable is made from special grade of resistant PVC compound impervious to water, grease oil etc. Rigid test & checks at every stage from raw material through production and finally up to the finished product insure that MEHAL cables are of highest quality to meet the International Standard.
| Conductor | Insulation | Sheath Overall Dimensions | Conductor Resistance @20°C (max.)ohms/km. | Current Carrying Capacity @ 40°C (Amp.) | |||
|---|---|---|---|---|---|---|---|
| Area (Nom.) Sq. mm. | No./size of Wires mm | Thickness (Nom) mm. | Thickness (Nom) mm. | Width ‘W’ mm | Thickness ‘T’mm | — | — |
| 1.5 | 22/0.3* | 0.6 | 0.90 | 11.70 | 5.40 | 12.10 | 14 |
| 2.5 | 36/0.3* | 0.7 | 1. 00 | 13.50 | 6.20 | 7.41 | 18 |
| 4 | 56/0.3** | 0.8 | 1.00 | 15.20 | 6.50 | 4.95 | 2 |
*As per Conductor Class 2 of IS: 8130 : 1984
**As per Conductor Class 5 of IS: 8130 : 1984
3 Core Flat Cables generally conforming to IS:694:1990
| Conductor | Insulation | Sheath Overall Dimensions | Conductor Resistance @ 20°C (max.) ohms/km. | Current Carrying Capacity @ 40°C (Amp.) | |||
|---|---|---|---|---|---|---|---|
| Area (Nom.) Sq. mm. | No./size of Wires mm | Thickness (Nom) mm. | Thickness (Nom) mm. | Width ‘W’ mm | Thickness ‘T’mm | — | — |
| 6.0 | 84/0.3 | 1.0 | 1.15 | 17.30 | 7.60 | 3.30 | 31 |
| 10.0 | 140/0.3 | 1.0 | 1.40 | 23.70 | 9.90 | 1.91 | 42 |
| 16.0 | 226/0.3 | 1.0 | 1.40 | 28.00 | 11.40 | 1.21 | 57 |
Selection Guide for 3 Core Flat Cables
1) HP Vs Current: The full load current for submersible pump motors, 3 phase, 50 cycles, 415~425 V.
| Hp | 5.0 | 7.5 | 10.0 | 12.5 | 15.0 | 17.5 | 20.0 | 25.0 | 30.0 | 35.0 | 40.0 | 45.0 | 50.0 | 55.0 | 60.0 | 65.0 | 70.0 | 75.0 | 80.0 |
| Amp | 7.5 | 11.0 | 14.9 | 18.9 | 22.5 | 25.2 | 28.4 | 35.6 | 42.3 | 50.4 | 58.1 | 62.1 | 67.5 | 73.8 | 81.0 | 87.3 | 93.6 | 100.80 | 108.0 |
2) Derating Factors: Multiply the current carrying capacity of the cable by factors given below for various ambient temperatures.
| Ambient Temperature C | 30 | 35 | 40 | 45 | 50 |
| Operating Factor | 1.09 | 1.04 | 1.00 | 0.95 | 0.77 |
Note : Supplied in 500 meter packing on bags and Drums. Can also supplied in 100 mtr., 300 mtr., 1000 mtr packing on request. The strand diameter is nominal however, construction of conductor is design to satisfy the requirement of conductor resistance as per IS : 8130 : 1984
